This flowmeter is based on the transit-time measurement principle and features an open-structure design, making it ideal for precise flow measurement in main and branch channels of water conservancy and irrigation systems.
It integrates an ultrasonic velocity measurement unit and a radar water level unit to accurately measure water flow through layered velocity and water level data.
The device can be easily connected to RTUs, lithium batteries, solar chargers, and other equipment to enable data storage and real-time transmission of water level and flow information.
It offers high measurement accuracy, excellent reliability, and simple maintenance.
Open-channel and sluice gate flow measurement and monitoring for water conservancy, agriculture, and irrigation systems.
Flow measurement and monitoring for urban drainage systems.
| Project | Indicator |
| Model | LS FMU-1XSSNG |
| Speed Measurement Range | ±0.01 m/s to ±5m/s |
| Number of Flow Measurement Layers | 1st to 8th floor, customizable for additional floors |
| Measurement Error (GB/T 11826.2-2012) | ≤0.1m/s: error ±0.008m/s; 0.1-5m/s: error ±2.5% |
| Measurement Resolution | 0.001m/s (flow velocity) |
| Level Detection Range | 0-15m |
| Level Detection Accuracy | ±2mm |
| Data Transmission Method | RS485, MODBUS protocol: electrostatic discharge, surge, reverse polarity protection |
| Temperature Detection Range | -25~80℃ (GB/T 15966-2017) |
| Electromagnetic Interference Resistance | Meets GB/T 11826.2-2012 6.2.4 |
| Water Temperature Detection Accuracy | Not exceeding ±0.2℃ (GB/T 15966-2017) |
| Operating Temperature | -25℃ to 80℃ (GB/T 11826.2-2012 requirements) |
| Storage Temperature | -40℃ to 80℃, relative humidity not more than 85% (GB/T 11826.2-2012) |
| Operating Voltage | 7-32VDC |
| Operating Current | Average current <20mA at 12VDC, peak current <200mA |
| Insulation | Sensor power supply to shell insulation resistance not less than 5MΩ (GB/T 15966-2017) |
| Protection Level | IP68 |
| Lightning Protection | Lightning protection level 6KV |
| Product Standards | GB/T 11826.2-2012 Flow Velocity and Flow Instruments, GB/T 15966-2017 Basic Parameters and General Technical Conditions for Hydrological Instruments |
| Specification | Supports ultrasonic range of 1m to 23m |
| Number of Transducers | Supports 1 pair to 8 pairs: other quantities can be customized |
