Multi-parameter water quality analyzer
High Precision, Indicator Type
Long-Term Stability
Integrated High-Pressure Resistant Structure
Full-Flow Detection
Flow Measurement for Equipment Water and Semiconductor Industry PCW Systems
| Model | LS FTF-1FMSHG |
| Measurement Medium | Liquid |
| Connection Standard | Corresponds to various standards including RC, G, NPT, flange, etc. |
| Installation Direction | Horizontal installation, vertical installation |
| Wetted Material | SUS304, 316L |
| Indicator Material | Acrylic or heat-resistant glass |
| Enclosure | Aluminum alloy |
| Measurement Tube | Acrylic |
| Medium Temperature | Standard: 60°C, Special temperature: Max. 120°C |
| Pressure | Standard: 1MPa |
| Accuracy | ±2% |
| Range Ratio | 10:1 |
| Flow Range | 0.3~500L/min |
