BWS-MP multi-parameter water quality analyzer
Utilizing fluorescence detection and digital intelligent design, this sensor features built-in temperature compensation, and supports calibration, data logging, analysis, and diagnostics. It uses an RS485 interface and standard Modbus protocol for real-time online monitoring of cyanobacteria.
When exposed to excitation light of a specific wavelength, cyanobacteria are stimulated to a higher energy state. As they return to their ground state, they emit fluorescence with a longer wavelength than the excitation light. The intensity of the emitted fluorescence is directly proportional to the concentration of cyanobacteria in the water.
Environmental surface water, aquaculture water, emergency monitoring
●Utilizes optical and digital filtering technology to eliminate stray light interference for accurate measurement
●Corrosion-resistant housing with IP68 waterproof rating for long-term underwater operation
●RS485 communication interface with standard Modbus protocol for easy integration
| Product Model | LS BGA-1FDNOG |
| Operating Principle | Fluorescence Detection Method |
| Measurement Range | Cyanobacteria: (200～300,000)Cells/mL; Temperature: (0~50)℃ |
| Repeatability | ≤1% |
| Zero Drift (24h) | ±1%F.S |
| Range Drift (24h) | ±3%F.S |
| Detection Limit | 200 Cells/mL |
| Resolution | 30 Cells/mL |
| Protection Grade | IP68 |
| Communication Interface | RS485, standard Modbus protocol, baud rate 9600, address 50 by default |
| Size Specification | (φ16*146) mm, cable 10 meters (customizable) |
| Material | 316L Stainless Steel/Titanium Alloy |
| Weight | 0.1kg |
| Installation Thread | Upper end M16*1, lower end M20*1.5 thread |
| Operating Voltage | (9~36)V DC |
| Mean Time Between Failures (MTBF) | ≥1440h/each |
| Energy Consumption | 0.4w |
| Cleaning Method | None |
| Calibration Cycle | 0–50°C |
| Operating Environment | 3 to 6 months |
