Utilizes diffused silicon pressure-sensing core
Suitable for both low-pressure (<20 kPa) and high-pressure (>40 MPa) measurement
High overload capacity with excellent shock resistance
Capable of differential pressure measurement
| Measured Medium | Compatible with liquids, gases, and vapors of 316 stainless steel |
| Accuracy | 0.1%F.S 0.25%F.S 0.5%F.S |
| Stability | 0.2% F.S |
| Measurement Range | -100kPa~60MPa |
| Supply Voltage | 12~24V DC |
| Output | 4~20mA DC two-wire system |
| Communication | HART Communication Protocol |
| Installation Interface | M20*1.5 |
| Operating Temperature | -10~+80℃ |
| Storage Temperature | -40~+125℃ |
| Relative Humidity | Less than 95% |
| Overload Limit | 1.5 to 2 times the rated range |
| Load Resistance | Does not exceed 600Ω to maintain constant current output |
| Zero Temperature Coefficient | Less than 0.02%/℃ |
| Full Scale Temperature Coefficient | Less than 0.02%/℃ |
| Isolation Diaphragm | 316 Stainless Steel |
| Mechanical Protection | IP65 |
| Explosion Proof Rating | iall CT5 |
