Multi-parameter water quality analyzer
Fresh Water
| Project | Technical Specifications |
| Model | LS HYRP-1AMSBG |
| Rain Collection Diameter | φ200mm |
| Blade Edge Angle | 40°~45° |
| Resolution | 0.2mm |
| Measurement Accuracy | ≤±2% (indoor artificial precipitation, based on the instrument's own drainage capacity) |
| Rain Intensity Range | 0mm~4mm/min (allowable maximum rainfall intensity 8mm/min) |
| Communication Method | RS485/NB-IoT/LoRa/α/2/4/5G |
| Power Supply Range | 4.5~30V |
| Maximum Power Consumption | 0.24W |
| Operating Environment | Ambient temperature: 0~70℃, relative humidity: <95% (at 40℃) |
| Sampling Interval | 0s~24h |
| Upload Interval | 0s~72h |
| Communication Standard | Complies with 'Technical Requirements for Geological Disaster Monitoring Data Communication' |
| Protection Grade | IP65 |
